Energy Guard Bulk Moulded Guard Supplier · Made to Your Movement Spec
Protective moulded guard for watch energy assemblies
- Snap-fit assembly — no adhesive required
- Impact and dust resistant profile
- Compatible with standard watch battery cells
- Lead time
- 7–14 working days
- Tolerance
- ±0.05mm
- Materials
- ABS, Polycarbonate, POM
Energy Guard price, MOQ & lead time
Per-piece price depends on material, finish and quantity, so we quote from your drawing or sample — usually within one working day. No account or registration needed.
- Price
- Quoted per drawing & quantity
- Minimum order
- Quoted per specification and volume
- Lead time
- 7–14 working days
- Supply
- OEM & wholesale · India & export
Energy Guard engineered for your assembly line
Material options
Energy Guard components are precision-moulded protective enclosures that shield battery compartments, power modules and sensitive internals from impact, dust and accidental contact. Manufactured in engineering-grade polymers with tight dimensional tolerances to ensure a secure snap-fit against the case body.
An energy guard is a precision-moulded enclosure that protects a watch's battery compartment and power module from impact, dust and accidental contact during assembly and service. Mahalaxmi Industries moulds energy guards in Greater Noida in ABS, polycarbonate and POM, designed for snap-fit assembly against the case body with no adhesive.
Guards are moulded at 0.8–2.0 mm thickness and held to ±0.05 mm on critical dimensions, so they seat securely without stressing the case. Standard watch battery cells are supported, and custom dimensions are moulded to your movement specification.
Energy Guard applications
Quartz watch assemblies
Guards that cover the battery compartment and keep the cell located during service.
Sports & kids' watches
Impact- and dust-resistant guards for watches that take knocks.
Proprietary modules
Custom guards moulded around in-house power modules.
Service & repair kits
Replacement guards supplied for after-sales service programmes.
How we manufacture Energy Guard
Production method, materials, variants and finishing — all handled in-house in Greater Noida.
Energy Guard
Injection Moulding
25 × 50T machines, 50 lakh+ pcs/month.
Reference library
3 samples on file
Engineered polymers
Custom finishes
Pantone / RAL match, multi-colour pad printing, PVD / electroplating.
How Energy Guard are made at Mahalaxmi
-
Movement & cell spec
Battery cell size and module layout define the guard's profile and snap features.
-
Tooling
Thin-wall moulds are built in our tool room for the 0.8–2.0 mm section.
-
Moulding
Guards are moulded in ABS, PC or POM with controlled shrinkage for a ±0.05 mm fit.
-
Snap-fit testing
Samples are fitted to the case body to confirm a secure snap without stress marks.
-
Inspection & packing
Dimensional and visual inspection before packing.
Which material for your Energy Guard?
| Material | Key property | Best for |
|---|---|---|
| ABS | Low cost, easy to mould thin walls | High-volume quartz watches |
| Polycarbonate (PC) | High impact strength | Sports and kids' watches |
| POM | Dimensionally stable, good snap-fit life | Guards that are removed for service |
Not sure which to pick? Send your drawing and we will recommend a material for the finish, tolerance and volume you need.
Energy Guard specifications
| Fit Type | Snap-fit |
|---|---|
| Thickness | 0.8mm – 2.0mm |
| Tolerance | ±0.05mm |
| Production Method | Injection Moulding |
| Lead Time | 7–14 working days |
Why OEMs choose our Energy Guard
- Snap-fit assembly — no adhesive required
- Impact and dust resistant profile
- Compatible with standard watch battery cells
- Tolerance: ±0.05mm on critical dimensions
- Materials: ABS, PC, POM
- Custom dimensions per your movement spec
Custom Energy Guard options
- Custom dimensions per movement and battery cell
- 0.8–2.0 mm wall thickness
- ABS, PC or POM material
- Snap-fit geometry to suit your case body
- Colour matched to internal components
How we inspect every Energy Guard batch
- ±0.05 mm tolerance on critical dimensions
- Snap-fit verified on the actual case
- Visual check for flash and stress marks
- First-off sample approval before production
Services behind our Energy Guard
Energy Guard variants & samples
A single-source Energy Guard supplier in India
How to order Energy Guard
-
Send your drawing or sample
Share a 2D/3D drawing, a reference part or even a competitor sample. We confirm feasibility, material and tolerance within one working day.
-
Quote & tooling plan
You receive a piece price, tooling cost (if a new mould is needed), MOQ and lead time. Existing moulds skip straight to sampling.
-
Sample approval
We mould first-off samples, inspect them against your drawing and ship them for your fit and finish sign-off.
-
Production & dispatch
Approved samples become the production standard. Batches are inspected at every stage and packed to your specification.
Energy Guard — buyer questions
Sizes, materials, tolerances, pricing and lead times buyers ask about before placing an order.
Question not answered here? Send your drawing or a description and we will reply with a specific answer, not a brochure.
Ask a question
What does an energy guard do in a watch?
It is a moulded enclosure that shields the battery compartment, power module and sensitive internals from impact, dust and accidental contact.
How is the energy guard fitted?
Snap-fit against the case body — no adhesive is required. Tolerances of ±0.05 mm keep the fit secure across production runs.
Which materials are used?
ABS, polycarbonate or POM engineering polymers, moulded at 0.8–2.0 mm thickness.
Can the guard be made to our movement dimensions?
Yes. Guards are moulded to your movement and battery-cell specification; standard watch battery cells are supported.
What is an energy guard and why does a watch need one?
It is the moulded component that protects and locates the battery and the surrounding movement area, keeping contact pressure consistent and preventing the cell from shifting inside the case. A poorly fitting guard shows up as intermittent stopping, which is a warranty return rather than a cosmetic complaint.
Can you make an energy guard for our movement and case?
Yes. Send the movement, the case and the battery specification — or a sample assembly — and we will design to the actual stack-up rather than nominal figures.
We hold ±0.05 mm on these parts, tightening where contact geometry demands it.
Which materials are best for an energy guard?
ABS where cost and mouldability lead, polycarbonate where impact resistance matters, POM where the part must hold dimension under sustained contact load. The right answer depends on the case construction and how the guard is retained.
Describe the assembly and we will recommend the grade.
What are the minimum order and lead time?
Quoted per specification and volume rather than a fixed MOQ, with 7–14 working days from sample approval on existing tooling. Pilot quantities are accepted on a first order.
Send the specification for a quote within one working day.
